    Metal Seated Floating Ball Valve , Forged Steel Ball Valve Inch 1/2" - 12"

    Ask Lasest Price
    Brand Name : Zaval
    Model Number : BLFF910
    Supply Ability : negotiable
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    Metal Seated Floating Ball Valve , Forged Steel Ball Valve Inch 1/2" - 12"

    Metal Seated Floating Ball Valve Forged & Casted 2PC, Inch1/2"-12" Class150-2500


    Zaval metal-seated floating ball valves can be applied in wide pressure and temperature ranges (150LB~2500LB and -46~450℃). The metal seat provides an optimal resistance against wear caused by abrasive services or hard particles.


    Design Feature



    1. Top flange design as per ISO 5211, optional actuators of gearbox, electric actuator and pneumatic actuator are available.
    2. Hard faced ball and the seat to satisfy the requirement of high hardness, high temperature resistance, wear resistance.
    3. With the help of the pre-loaded spring, the seat is able to maintain seal even in low operating pressure.
    4. Several designs of the seat to choose from, among which the dust proof seat design is available.

    Specifications


    DesignASME B16.34/API 6D
    Face to FaceASME B16.10/API 6D
    End to EndASME B16.10/API6D
    End FlangeASME B16.5/B16.47A
    BW EndASME B16.25
    TestAPI 6D
    Fire Safe TestAPI607/API 6FA
    SpecialNCAE MR0175
